New RadioMaster TX16S MKII MAX FCC LBT V4.0 Hall Gimbals Radio Control System ExpressLRS or Multi-protocol 4in1
38 orders (reference)
Description
New RadioMaster TX16S MKII MAX FCC LBT V4.0 Hall Gimbals Radio Control System ExpressLRS or Multi-protocol 4in1 ============================================================ Features Improved internal circuitry and optimized power supply. New charge circuitry with integrated reverse-polarity protection. Optimized charge IC now allows up to 2.2A internal USB-C charge current. Rear-mounted audio jack provided headphone output. V4.0 Gimbal improved centering and temperature stability Optional high/low rear grips are included for improved ergonomics. Improved S1/S2 knobs with clear center detents. Improved LS/RS Sliders with smoother feel and better center detents. Redesigned battery cover for improved battery access. Retooled body shell with improved fit and finish. Trainer socket changed to standard TRS 3.5mm socket. Rear DIY Socket added for personalized mods. Improved internal plastics for better longevity. Built-in ExpressLRS Backpack and 4in1 versions. Specification Items: TX16S Mark II Max Size: 287x129x184mm Weight: 750g (without battery) Transmission frequency: 2.400GHz-2.480GHz Transmitter module: Option 1: Internal 4-in-1 multi-protocol module (CC2500 CYRF6936 A7105 NRF2401)； Option 2: Internal ELRS (SX1280) SD card: 256MB by default, 8GB maximum Antenna gain: 2db (transmit power adjustable) Working current: 400mA Working voltage: 6.6-8.4v DC Radio firmware: EdgeTX Module Firmware: Multiprotocol- Module (4IN1) -OR- ExpressLRS (ELRS) Channels: Up to 16 channels (depending on the receiver) Display: 4.3-inch TFT full-colour touch display with a resolution of 480 * 272 Gimbal:V4.0 Hall sensor with Aluminium fasci Module Bay: JR compatible module bay Upgrade method: Supports USB-C online / SD card offline upgrade Notes: ★ 4in1 (standard) Version supports all MPM protocols ★ ELRS (standard) is pre-installed witn ExpressLRS ISM FW (Max power is hardware dependnant) ★ 4in1 LBT Version (Europe)is limited to LBT compliant protocols FrSKY X/X2 LBT, HoTT LBT and DSMX ★ ELRS LBT (Europe) Version is pre-installed with ExpressLRS CE EU domain LBT FW (Limited to 100mw power output) TECHNICAL SPECIFICATIONS • Size: 287x129x184mm • Weight: 750g (without battery) AVAILABLE OPTIONS China Mainland ELRS FCC Red 4IN1 FCC Red ELRS FCC Blcak 4IN1 LBT Blcak ELRS FCC Red-B 4IN1 FCC Red-B ELRS FCC Blcak-B 4IN1 LBT Blcak-B PRODUCT INFORMATION Brand: RadioMaster Category: Radio Transmitter Wholesale Price: US $279.95 ————————————————————————————————————————
Specifications
| Attribute | Value |
|---|---|
| High-concerned chemical | None |
| Package | Yes |
| Weight | 1.6kg |
| Model Number | TX16S MAX |
| Brand Name | RADIOMASTER |
| Origin | Mainland China |
| Certification | CE |
| Drones Accessories Type | Flight Controller |
Product Details
Features
Improved internal circuitry and optimized power supply.
New charge circuitry with integrated reverse-polarity protection.
Optimized charge IC now allows up to 2.2A internal USB-C charge current.
Rear-mounted audio jack provided headphone output.
V4.0 Gimbal improved centering and temperature stability
Optional high/low rear grips are included for improved ergonomics.
Improved S1/S2 knobs with clear center detents.
Improved LS/RS Sliders with smoother feel and better center detents.
Redesigned battery cover for improved battery access.
Retooled body shell with improved fit and finish.
Trainer socket changed to standard TRS 3.5mm socket.
Rear DIY Socket added for personalized mods.
Improved internal plastics for better longevity.
Built-in ExpressLRS Backpack and 4in1 versions.
Specification
Items: TX16S Mark II Max
Size: 287x129x184mm
Weight: 750g (without battery)
Transmission frequency: 2.400GHz-2.480GHz
Transmitter module: Option 1: Internal 4-in-1 multi-protocol module (CC2500 CYRF6936 A7105 NRF2401)； Option 2: Internal ELRS (SX1280)
SD card: 256MB by default, 8GB maximum
Antenna gain: 2db (transmit power adjustable)
Working current: 400mA
Working voltage: 6.6-8.4v DC
Radio firmware: EdgeTX
Module Firmware: Multiprotocol- Module (4IN1) -OR- ExpressLRS (ELRS)
Channels: Up to 16 channels (depending on the receiver)
Display: 4.3-inch TFT full-colour touch display with a resolution of 480 * 272
Gimbal:V4.0 Hall sensor with Aluminium fasci
Module Bay: JR compatible module bay
Upgrade method: Supports USB-C online / SD card offline upgrade
Notes:
★ 4in1 (standard) Version supports all MPM protocols
★ ELRS (standard) is pre-installed witn ExpressLRS ISM FW
(Max power is hardware dependnant)
★ 4in1 LBT Version (Europe)is limited to LBT compliant protocols FrSKY X/X2 LBT, HoTT LBT and DSMX
★ ELRS LBT (Europe) Version is pre-installed with ExpressLRS CE EU domain LBT FW (Limited to 100mw power output)
